1) Pixel: 20.8-16.667mm

2) Density: 2880dot/m²

3) LED Composition: 1R1G1B

4) Color: Pure Red + Pure Green + Pure Blue

5) Best Viewing Distance: 20-250m

6) Best Viewing Angle: horizontal:120. Vertical: 120

7) Environment Temperature: Storage:-40℃ ～+85℃，Working:  -30℃ ～ +80℃

8) Working Voltage: 100-220v

9) Average Consumption: 170W/m²

10) Max Consumption: ≤510W/m²

11) Refresh Rate: ≥2000HZ
12) Gray/Color: red/green/blue65536 levels, 16.7M colors
13) Brightness: ≥5000cd/m²
14) Brightness Adjustment way: software adjust 100 levels.

15) Screen Signal: PAL/NTSC

16) Screen input/output way: 8 ways for input/ 8 ways for output

17) Control system: PCTV+ DVI Display Card + Fullcolor Control System

18) Average trouble-free time: ≥10000 hours

19) Lifetime: 10,0000 hours

20) Flatness: every pixels ≤1mm Every modules ≤1mm

21) Uniformity: the brightness is uniformity

22) Heat dissipation: the structure strengthens natural convection

23) Lamp material: 6061 tensile aluminum

24) Transmittance:55%

25)  Protection level: IP65

26) EMC: Conduction Emission EN55022 CLASS-A、Harmonic Current IEC61000-3-2 Class-A

27) Wind resistance: level 12

28) Weight: 13.5kg/m 2

Protection Technoloty

Waterproof, Humidity Protection, Dust Protection, Rust Protection, Static-Protection, etc.

Media Support

BMP／JPG／GIF／PCX．．．

MPG ／MPEG／MPV／MPA／AVI／VCD／SWF／RM／RA／RMJ／ASF．．．
